專業P 系列 CO2雷射廠商

Average Output Power

> 90 Watts (10.2 μm)
> 100 Watts (10.6 μm)

> 150 Watts

> 250 Watts

> 400 Watts

Peak Pulse Power

375 Watts (10.2 μm)
400 Watts (10.6 μm)

600 Watts (9.3, 10.6 μm)
550 Watts (10.2 μm)

750 Watts (10.2 μm)
800 Watts (10.6 μm)

1 kW

Wavelength

10.2 μm, 10.6 μm

9.3 μm, 10.2 μm, 10.6 μm

10.2 μm, 10.6 μm

10.6 μm

Beam Quality (M²)

< 1.2

< 1.2

< 1.2

< 1.2

Power Stability (cold start)

± 7%

± 5% (9.3 μm)
± 6% (10.6, 10.2 μm)

± 5%

± 7%

Beam Diameter

7.5 mm ± 1.1 mm (10.2 μm)
8.0 mm ± 1.0 mm (10.6 μm)

8.5 mm ± 1.0 mm

8.0 mm ± 1.0 mm (10.2 μm)
9.0 mm ± 1.0 mm (10.6 μm)

6.5 mm ± 1.0 mm (option 1)
9 mm ± 1.0 mm (option 2)

Operating Frequency

0 – 100 kHz

0 – 130 kHz

0 – 100 kHz

0 – 100 kHz

Duty Cycle Range

< 37.5%

< 37.5%

< 45%

≤ 50%

Cooling

Water

Water

Water

Water

Dimensions (LxWxH) mm (in.)

590 x 132 x 155 (23.2 x 5.2 x 6.1)

798 x 132 x 155 (31.4 x 5.2 x 6.1)

1252 x 315 x 198 (49.3 x 12.4 x 7.8)

1262 x 208 x 300 (49.7 x 8.2 x 11.8)

Weight kg (lbs.)

13.6 kg (30 lbs.)

18.1 kg (40 lbs.)

48.5 kg (107 lbs.)

59 kg (130 lbs.)
