Wavelength

Any wavelength to be selected between 700 nm and 1700 nm (see wavelength table on datasheet (last page)

Optical bandwidth (nm)

From 20 nm to 110 nm to be selected (see wavelength table on datasheet)

Extinction ration (dB, typ)

50 dB

40 dB

Max input power

See wavelength table on datasheet (last page)

Switching speed (typ)

1 ns

<1 ns

2 ns

Dynamic range (up to)

60 dB

48 dB

Small signal gain

From 22 to 40 dB (see wavelength table next page)

Trigger-to-pulse Jitter / internal trigger Jitter

<20 ps / <20 ps

<8 ps / <8 ps

<2 ns / <100 ps

Pulse shaping

On-Off only

Yes (500 ps resolution)

CW offset (in pulse mode)

no

yes

no

Max pulse duration

Internal pulse generator : 500 ns / External pulse generator : <1 ns up to CW

8 µsec

Max repetition rate

10 MHz

250 MHz

20 MHz

Compatibilities & Libraries

USB - Windows 7/10 ; DLLs - Hexa - Labview - Python

Dimensions (mm)

190*150*45

208*100*37

Power supply

12 V (110 - 220 V adapter included)

24 V (110-220 V adaptator included)
