Maple-355-3

Fundamental Center Wavelength

355nm

Output Power Energy

> 3W
> 70µJ@50kHz

Repetition Rate

20 kHz – 200 kHz

Pulse Width

< 20ns @50kHz

Spatial Mode

TEM00 (M2≤1.2)

Beam Divergence

≤ 2mrad

Astigmatism

< 0.2

Beam Circularity

≥ 90%

Polarization Ratio

> 100:1

Polarization Direction

Horizontal

Beam Pointing Stability

< 25 μrad/°C

Pulse Energy Stability

≤ 3% RMS

Power Stability

≤ 3% RMS

Long-term Pointing Stability

< 25 μrad/°C

External Comms

RS-232

Beam Diameter, 0.3m in Front of Laser

≤ 2mm

Working Material

Nd:YVO4

Warm-up Time

< 15min

Operating Temperature

+10 to +30°C

Operating Humidity

< 65%

Non-Operation(Storage) Temperature

-10 to +45°C

Shipping Temperature(Non-condensing)

-10 to +45°C

Cooling

Air

Power Supply（Consumption）

110/220V AC, 50/60 Hz（600W）

Classification

Class 4
